Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine

    Buy cheap Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine from wholesalers

    Buy cheap Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine from wholesalers
    • Buy cheap Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine from wholesalers

    Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine

    Ask Lasest Price
    Brand Name : TECHANG
    Model Number : TCXZS
    Certification : CE
    Price : Negotiatable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine


    Rubber Powder Rotary Vibrating Screen Sieving Machine


    Introduction


    Rubber Powder Rotary Vibrating Screen Sieving Machine is a high precision fine powder sieving machine. The fundamental principle of Rubber Powder Rotary Vibrating Screen Sieving Machine is that the eccentric hammers installed on the top and bottom ends of motor changes the rotation motion of motor to horizontal, vertical and inclined three-dimensional motions, and then passes this motion to screen surface, achieving the purpose of classification, filtering and removal of impurities.

    Rubber Powder Rotary Vibrating Screen Industrial Sieving Machine

    Application


    Rubber Powder Rotary Vibrating Screen Sieving Machine is widely used in food industry, mining industry, chemical industry, medical industry, waste treatment, etc. Main functions are removing impurity, filtering, classification of material, solid-liquid separation, screening.


    1. Food industry: sugar powder, starch, salt, rice powder, milk powder, soybean milk, egg powder, soy sauce, juice, etc.

    2. Other industries: waste oil, waste water, dyeing and finishing waste water, paper making, additives, activated carbon.

    3. Metals, metallurgy and mining: aluminum powder, lead powder, copper powder, ore, alloy powder, welding rod.

    4. powder, manganese dioxide, electrolytic copper powder, Electromagnetic material, grinding powder, refractory materials, kaolin, lime, alumina, heavy calcium carbonate, quartz sand, etc.

    5. Chemical industry: resin, paint, industrial drugs, cosmetics, paint, herbal powder and so on.



    Structure


    1. Rubber Powder Rotary Vibrating Screen Sieving Machine can be used with single or multilayer screen decks, If your purpose is removing impurity, choosing single deck is ok. If you choosing three decks, means the materials will be graded to be four kinds sizes.

    2. Rubber Powder Rotary Vibrating Screen Sieving Machine can be made of stainless steel, carbon steel, pp materials according to different application.

    3. Rubber Powder Rotary Vibrating Screen Sieving Machine is designed by our professional engineer, every process is controlled strictly by quality inspection personnel, such as raw material cutting, forming, welding, polishing, painting, and so on.


    Specific data


    Rubber Powder Rotary Vibrating Screen Sieving Machine can be up to 5 layers, and the mesh size can reach 500 mesh. We will choose a suitable model according to your specific materials and application.



    Model

    PowerDiameter of screen surfacelayerMesh size
    TCXZS6000.37kw560mm1-50-500mesh
    TCXZS8000.55KW760mm1-50-500mesh
    TCXZS10000.75KW930mm1-50-500mesh
    TCXZS12001.5KW1130mm1-50-500mesh
    TCXZS15002.0KW1430mm1-50-500mesh
    TCXZS18002.2KW1730mm1-50-500mesh
    TCXZS20002.5KW1930mm1-50-500mesh

    Features


    1. Long working life:Each screen cloth is held in uniform tension by drawing it taut on tension rings. The drum-tight screening surface vibrates freely without whipping against rigid supports, greatly reducing screen wear and increasing screen life.

    2. Economy—Long Life, Less Power, Low Maintenance:Simplicity of design with few moving parts assures long life with little maintenance. Because of efficient design, Round separator requires less horsepower than other units of similar capacity. Remarkably long working life and the ease with which screens may be changed result in further economies.

    3. Less space required:For equivalent capacity, mobile vibrating screen require less working space than other screening equipment. Normally, a set of round separator can fit in your existing production line.

    4. Single or Multiple Separations:As many as five screen decks can be incorporated in one round separator, providing simultaneous separation into six fractions.


    Rubber Powder Rotary Vibrating Screen Sieving Machine consist of top cover, screen frame, screening mesh, clamp, vibrator, vibration motor, support base, and so on.
